Dust Explosion Proof Lighting: Zone 21 and Zone 22 Selection for Bulk Plants

Date: 2026-10-01

Dust-classified areas are the ones that go wrong quietly. There is no visible gas cloud to prompt a walk-down, the hazard hides inside silos, mills and conveying systems, and the dust zones on the site drawing rarely draw the same attention as the gas side. Yet a mill, a grain terminal or a palm-oil plant carries a fixture count as large as any refinery, and it is specified against a different marking from the gas side. This page sets out where dust-classified lighting demand sits, what changes in the specification when the hazard is dust rather than gas, and which formats carry the duty. The fixture count is easy to underestimate, because the classified points sit where material moves rather than where people work.

Grain silos and conveying structures at dusk, with high-mounted luminaires across the plant
Grain silos and conveying structures — the enclosure-side protection concept, not the gas marking, is what carries a dust-classified area.

Where dust-classified lighting demand sits

Dust-classified luminaires are bought by plant type, and the plants that carry the largest fixture counts share a common shape: bulk material is moved, dropped and stored, and every transfer point is a potential dust cloud. Four plant types account for most of the demand.

Plant typeTypical locationWhat drives the lighting spec
Grain, feed and flour plantsSilos, elevator legs, milling floors, bin tops, loading spoutsThe highest dust concentration in the plant sits at transfer and filling points; wash-down and cleaning cycles add moisture; surface temperature limits are tight for organic dust
Oilseed and palm-oil millsKernel crushing, conveying galleries, storage and loading baysContinuous operation through a crushing campaign, oily dust that cakes onto surfaces, and long runs where uniform line light beats spot lighting
Chemical, pigment and plastics plantsPowder handling, bagging lines, mixing and storage areasDust group can move from IIIB toward IIIC where fine conductive powders appear; the marking has to be confirmed point by point, not assumed from the plant type
Coal, cement and metals handlingCrushers, transfer towers, mills, conveyor galleries, loadoutVery high dust load, abrasive and conductive powders, heavy vibration, and fixed mounting positions with almost no access for relamping

The practical consequence: one plant orders the same luminaire family for silos, galleries and loadout, and the specification that survives is the one written for the worst point — the highest dust concentration, the tightest surface-temperature limit and the least accessible mounting position. In practice the worst point moves with the campaign: a mill that switches products changes the dust group it must cover, and a terminal that takes a different material changes the surface-temperature data behind the marking. That is why the family is selected once against the harshest combination the plant can present, and why the certificate for the type actually supplied is checked against that combination rather than against the plant name on the purchase order.

What changes when the hazard is dust

Selection still runs on the zone, but three things move when the classified area is dust-classified rather than gas-classified, and each of them changes the marking a fixture must carry.

Selection axisWhat it changesOur data point
ZoneDust zones run 20 / 21 / 22, and the protection is an enclosure concept rather than a flameproof oneZone 21 and Zone 22 duty met with Ex tb enclosure protection; the concept is matched to the zone on the area-classification drawing
Dust groupIIIA for combustible flyings, IIIB for non-conductive dust, IIIC for conductive dust such as metal powder and carbon blackGroup is read point by point off the area-classification drawing — a IIIB rating cannot be extended to IIIC by catalogue description
Surface temperatureLimited against the ignition temperature of the dust cloud and of the dust layer, which are not the same numberSurface temperature verified against the dust data for the material handled; the marking is confirmed per type before selection
Ingress protectionDust ingress and wash-down both place demands on the seal and the housingIngress protection and seal arrangement confirmed against the cleaning regime at the mounting point
Cleaning accessDust that settles on the fixture insulates it and builds up on optical surfacesHousing shape and mounting chosen so that settled dust sheds and clean-down is practical without tools
An industrial bulk-handling plant at night with high-mounted luminaires along conveying structures
A bulk-handling plant at night — where settled dust, not the catalogue output, is what limits how the fixture performs between clean-downs.

Matching format to duty

Once the zone, the dust group and the surface-temperature limit are fixed, the remaining choice is the physical format, and in a dust plant the geometry and the cleaning regime usually decide it. A gallery that is washed down weekly asks a different question from a dry transfer tower cleaned once per campaign, and the same fixture rarely answers both.

  • Galleries, conveyors and silo runs. Conveying galleries and silo rows are long, narrow and continuous, and the light has to reach both the walkway and the belt without throwing shadow onto the moving material. A linear format gives that uniformity with fewer fittings and a housing shape that sheds settled dust; the LU Series LED linear luminaire covers those runs for Zone 22 duty, while the Zone 21 case — conductive dust, where a Zone 22 rating cannot be extended — is carried by the LO Series explosion-proof linear light, whose Ex tb enclosure covers Zone 21 as well as Zone 22.
  • Bin tops, loadout and open handling areas. Filling points, loadout bays and open storage need throw rather than line light, and a floodlight format carries the output; the FL8 Series explosion-proof floodlight is specified for that duty.
  • Confined and temporary positions. Silos, bins, tunnels and maintenance positions need a compact pendant or portable format rather than a fixed high-output unit.

Formats and mounting at a glance

The table below maps the common positions in a dust plant to the format that usually carries them. The zone and the dust group at each point come from the area-classification drawing; the surface-temperature limit comes from the material handled.

Position in the plantFormat that usually carries itTypical coverageTypical mounting
Conveying galleries, silo rows, elevator legsLinear luminaireZone 22 (Ex tb), dust group per the drawingGallery rail or wall bracket
Bin tops, loadout bays, open storageFloodlightZone 22 (Ex tb)Pole or plant structure
Silos, bins, mixer internalsPendant or compact fittingMatched to the pointPendant or bracket
Cleaning and maintenance positionsPortable or task lightTask-dependent, confirmed per unitLocal arrangement

Both formats ship with the IECEx and ATEX evidence set out below; the certificate that applies is the one listed against the specific type, not inferred from the series name.

What we provide

The manufacturer's side of the technical file is what we hold and what we hand over. Every number below is stated as issued, and the certificate for a given type is the one listed against that type.

DocumentNumberIssued by / covers
ATEX Type Examination CertificateCSANe 25 ATEX 1229XCSA Group (Netherlands notified body) — LO series
IECEx Certificate of ConformityIECEx CSA 25.0093XCSA Group — LO series
ATEX Quality Assurance Notification (QAN)CSANe 26 ATEX M076CSA Group Netherlands — LO series
IECEx Quality Assessment Report (QAR)GB/CSAE/QAR26.0002/00CSA Group (UK) — LO series
ATEX Type Examination CertificatesTÜV CY 26 ATEX 0207611 / 0207612 / 0207613 XTÜV (Cyprus); correspond to the FL8, GS and LU series

In practice we supply the IECEx test reports, the IECEx Certificates of Conformity, the IECEx QAR, the ATEX certificates and the quality assurance notification — the technical evidence a project needs in order to assess the equipment — together with installation manuals and the parameter set below. Where a project needs a marking not listed here, the type and its certificate are confirmed before the quotation is issued.

What we need from you to quote

For a quote and lead time, please provide: the area-classification drawing (Zone 20/21/22, the dust group and the dust data for the material handled); the required surface-temperature limit and the ambient temperature range; the required illuminance and uniformity for each task; the cleaning regime and the mounting arrangement (silo wall, gallery rail, bin top, pole or bracket); the supply voltage and frequency; and the project node and required arrival time. With those we can match the protection concept, the dust-group coverage and the format to the duty, and return a bill of materials rather than a single catalogue item.

Frequently asked questions

What is the difference between Zone 21 and Zone 22 lighting?

Zone 21 covers areas where a dust cloud is likely to occur in normal operation, and Zone 22 covers areas where it is unlikely and, if it occurs, only briefly. Both are met with an enclosure protection concept rather than a flameproof one, but the zone decides how the enclosure and the surface temperature have to be rated. The zone is always read off the project's own area-classification drawing. Where a plant spans both, the fixture is selected for the stricter zone and confirmed against the drawing rather than averaged between the two.

Can a gas-rated luminaire be used in a dust-classified area?

Not automatically. The zone system, the group and the surface-temperature basis are different on the dust side, and a marking that covers a gas group does not by itself cover a dust group. A fixture only serves a dust-classified area when its marking covers the dust zone and dust group it is installed in, which is why the certificate is checked against the specific installation point.

Why does the surface-temperature limit matter so much with dust?

Because a dust layer insulates the surface it settles on, so the same fixture can run hotter under a layer than it does in clean air, and the limit is read against the material actually being handled rather than a single blanket figure. That is why the dust data for the powder or the grain in question is part of the specification, not an afterthought.

Which format suits silos, conveyors and loadout areas?

Conveying galleries and silo rows are long, narrow and continuous, so a linear format gives uniform light along the walkway and the belt with fewer fittings and a housing that sheds settled dust. Bin tops, filling points and loadout bays are discrete high points where throw matters more than line light, so a floodlight format is the right tool. Most plants use both.

How is lighting affected by wash-down and cleaning routines?

Wash-down places a repeated demand on the seals and the cable entry, and cleaning access decides how often settled dust is actually removed from the fixture. Both are part of the selection rather than an installation detail: the ingress protection and the housing shape are matched to the cleaning regime at the mounting point, so clean-down stays practical between maintenance intervals.
